YJJ 3ST/F AD004-J04 0-100PPM3 Series Sulfur Dioxide (SO2) Sensor

Brand Name : CITY

Model Number : 3ST/F AD004-J04

Place of Origin : Britain

MOQ : 1

Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram

Supply Ability : 2200

Delivery Time : 3 days

Packaging Details : canning

Nominal Range : 0-100ppm

Maximum Overload : 500ppm

Inboard Filter : To remove H2S

Expected Operating Life : Two years in air

Contact Now

Product Description:

3ST/F AD004-J04 0-100PPM3 Series Sulfur Dioxide (SO2) Sensor

Features:

Nominal Range 0-100ppm

Maximum Overload 500ppm

Inboard Filter To remove H2S

Expected Operating Life Two years in air

Output Signal 0.37 ± 0.07 µA/ppm

Resolution 0.5ppm

Temperature Range -20° to +50°C

Pressure Range Atmospheric ± 10%

Pressure Coefficient 0.015 % signal/mBar

T90 Response Time £20 seconds

Relative Humidity Range 15 to 90% non-condensing

Typical Baseline Range -0.25 to +0.5ppm equiv.

(pure air)

Maximum Zero Shift 1ppm equivalent

(+20°C to +40°C)

Long Term Output Drift <2% signal loss/month

Recommended Load 10W

Resistor Not required

Bias Voltage

Repeatability 1% of signal

Output Linearity Linear

Specifications:

Resolution 0-100 ppm
Resistor No required
Bias Voltage
Output Linearity Linear

YJJ 3ST/F AD004-J04 0-100PPM3 Series Sulfur Dioxide (SO2) Sensor


Product Tags:

3ST/F Sulfur Dioxide Sensor



YJJ Sulfur Dioxide Sensor


Wholesale YJJ 3ST/F AD004-J04 0-100PPM3 Series Sulfur Dioxide (SO2) Sensor from china suppliers

YJJ 3ST/F AD004-J04 0-100PPM3 Series Sulfur Dioxide (SO2) Sensor Images
