TGS3870 Methane And Carbon Monoxide Sensor Low Power Consumption

Brand Name : Figaro

Model Number : TGS3870

Place of Origin : Japan

MOQ : 1

Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram

Delivery Time : 3-5workingdays

Packaging Details : Standard Package

Model number : TGS3870-F00

Sensing principle : MOS type

Standard package : Plastic base and metal can

Target gases : Methane and Carbon Monoxide

Typical detection range : Methane 1~25% LEL

Contact Now

TGS3870 Methane And Carbon Monoxide Sensor Low Power Consumption

Features:
* Miniature size and low power consumption
* High sensitivity and selectivity to both
methane and carbon monoxide (CO)
* Low sensitivity to alcohol vapor
* Long life and low cost

Applications:
* Combination methane and carbon monoxide detectors
* Safety measures for lithium-ion batteries

Heater voltage VHH = 0.9V±3% for 5 sec
Circuit voltage 5.0±0.2V DC pulse
Load resistance Variable (>0.75kΩ)
Sensor resistance 0.3kΩ~5.0kΩ in 3000ppm methane
Sensitivity 0.44~0.7
Preheating period before test ≥5 days

TGS3870 Methane And Carbon Monoxide Sensor Low Power Consumption
